Produktinformationen

6C33C-B Triode Output Tubes with Fully Balanced Signal Path

Delivering 55 watts per channel, VK-80i uses four 6C33C-B triode output tubes for power delivery. They offer many times the current delivery of the 6550/KT90 tetrode tube variant used in most traditional tube integrated amplifiers. In addition to driving even difficult low-impedance speaker loads, the all-triode fully balanced design provides a natural portrayal of harmonic texture and instrumental timbre. Your recordings will sound more alive while simultaneously yielding greater finesse, grace, and inner detail.

"Fuse-less" Protection Circuit

In the event an output tube becomes over-stressed, all you need to do is turn VK-80i off and on again to restore normal operation. That's it. The elimination of internal fuses also contributes to a greater sense of ease and more natural reproduction of music. Also, the fuse-less protection circuit is combined with a world-class automatic-bias circuit that eliminates the constant need to set and readjust the proper bias of the output tubes. No tubes to bias. No tube fuses to replace.

Intelligent Auto-Bias Design Makes Operation a Cinch

The advanced engineering within VK-80i eliminates the traditional headache associated with most vacuum-tube power amplifiers—specifically, the constant need to set and readjust the proper bias of the output tubes. VK-80i features an intelligent automatic-bias design that adjusts for changing line voltage and aging tubes, with each output tube having its own dedicated bias circuit. The auto-bias circuit also ensures your VK-80i sounds wonderful within the first few minutes of listening.

Technische Daten

Leistung
Ausgangsleistung pro Kanal bei 8Ω/4Ω 55W
THD bei voller Leistung 3%
Frequenzgang und Impedanz
Frequenzgang 8Hz bis 200kHz
Eingangsimpedanz 215 kΩ
Röhrenbestückung
Röhren 4x6SN7, 4x6C33C-B
Stromverbrauch
Stromverbrauch im Leerlauf 400W
Stromverbrauch bei voller Leistung 800W
Anschlüsse und Steuerung
Signaleingänge 1 XLR, 3 RCAs
Lautstärkeregelung Resistive Ladder, 90 Stufen, 1dB pro Stufe
Fernbedienung Ja – Vollmetall
Abmessungen und Gewicht
Abmessungen (cm) 44 x 21 x 41
Gewicht 21kg

Hersteller & Produktsicherheit

Hersteller Kontaktdaten
Name Balanced Audio Technology
Anschrift 1300 First State Blvd., Suite A
Postleitzahl 19804
Stadt Wilmington
Bundesland / Staat Delaware
Land Vereinigte Staaten von Amerika (US)
Telefon +1 302-999-8855
E-Mail info@balancedaudio.net
Informationen zum sicheren Umgang mit dem Produkt
PDF Download Sicherheitsdatenblatt
